NTN 6814ZZ DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 6814ZZ
IMS Product Code: 2140995
Packaging: Pack of 2
Description:
NTN 6814ZZ Deep Groove Ball Bearing
Radial/Deep Groove Ball Bearing - Straight Bore, 70 mm ID, 90 mm OD, 10 mm Width, Double Shielded, Without Snap Ring
Specifications
- Bore Type: Straight
- Bore Diameter: 70 mm
- Outside Diameter: 90 mm
- Overall Width: 10 mm
- Closure Type: Double Shielded
- Row Type: Single Row Non-Fill Slot
- Snap Ring Included: Without Snap Ring
- Internal Clearance: CN
- Operating Temperature Range: -40 to 250 degrees F
- Cage Type: Pressed
- Precision Rating: ISO Class 0
- Finish Coating: Uncoated
- Bearing Material: High Carbon Chrome Steel
- Cage Material: Steel
- Radial Dynamic Load Capacity: 3010 lbf
- Radial Static Load Capacity: 2680 lbf
- Weight: 0.29 lbs
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 8 hours and 58 minutes.
