NTN 6901LLU DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 6901LLU
IMS Product Code: 2128840
Packaging: Sold Individually
Description:
NTN 6901LLU Deep Groove Ball Bearing
Deep groove ball bearing with straight bore, double sealed, and CN internal clearance.
Specifications
- Bore Type: Straight
- Bore Diameter: 12 mm
- Outside Diameter: 24 mm
- Overall Width: 6 mm
- Closure Type: Double Sealed
- Row Type: Single Row Non-Fill Slot
- Snap Ring Included: Without Snap Ring
- Internal Clearance: CN
- Operating Temperature Range: -40 to 250 degrees F
- Cage Type: Pressed
- Precision Rating: ISO Class 0
- Finish Coating: Uncoated
- Bearing Material: High Carbon Chrome Steel
- Cage Material: Steel
- Inner Ring Width: 6 mm
- Fillet Radius: 0.3 mm
- Max Rpm: 19000 rpm
- Series: 69
- Radial Dynamic Load Capacity: 710 lbf
- Radial Static Load Capacity: 330 lbf
- Weight: 0.02 lbs
- Seal Material: Nitrile Rubber
