NTN KR19LL CAM FOLLOWER
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: KR19LL
IMS Product Code: 2145137
Packaging: Sold Individually
Description:
NTN KR19LL Cam Follower
NTN KR19LL is a cam follower bearing with a spherical outer ring and needle roller bearing design. It features a through-hardened steel construction and is sealed on both sides.
Specifications
- type: Cam Follower
- material: Through Hardened Steel
- thread type: Metric
- cage material: Pressed Steel
- limiting speed - oil: 10000 RPM
- limiting speed - grease: 10000 RPM
- roller type: Crowned
- stud type: Standard
- bearing type: Needle Roller Bearing
- outside ring type: Spherical
- enclosure: Double Sealed
- drive type: Slot
- configuration: One
- torque: 8 N�m
- static load rating: 5400 N
- dynamic load rating: 4750 N
- load rating of track: 1380 N
- weight: 0.031 kg
- operating temperature range: -40 to 120 degrees C
- G: M8x1.25
- B1: 32 mm
- B2: 20 mm
- D: 19 mm
- D tolerance: 0/-0.05 mm
- B: 12 mm
- C: 11 mm
- d1: 8 mm
- d1 tolerance: 0/-0.015 mm
- G1: 10 mm
- e: 14 mm
- F: 10 mm
- C1: 0.6 mm
- n: 4 mm
- grease nipple size: NIP-B4
