NTN KR30XLLH CAM FOLLOWER
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: KR30XLLH
IMS Product Code: 1825515
Packaging: Sold Individually
Description:
NTN KR30XLLH Cam Follower
NTN KR30XLLH is a cam follower bearing with a cylindrical outer diameter and metric thread type. It features a through hardened steel material and pressed steel cage material.
Specifications
- Type: Cam Follower
- Material: Through Hardened Steel
- Thread Type: Metric
- Cage Material: Pressed Steel
- Roller Type: Cylindrical
- Stud Type: Standard
- Enclosure: Double Sealed
- Drive Type: Hex
- Configuration: One
- Outside Ring Type: Cylindrical
- Limiting Speed - Oil: 10000 RPM
- Limiting Speed - Grease: 10000 RPM
- Torque: 20.0 N·m
- Static Load Rating: 9650 N
- Dynamic Load Rating: 7850 N
- Load Rating of Track: 7700 N
- Weight: 0.090 kg
- Operating Temperature Range: -40 to 120 degrees C
- D: 30.000 mm
- D Tolerance: 0/-0.050 mm
- B: 15.000 mm
- C: 14.000 mm
- d1: 12.000 mm
- d1 Tolerance: 0/-0.018 mm
- G: M12x1.5
- B1: 40.000 mm
- B2: 25.000 mm
- B3: 6.000 mm
- a: 3.000 mm
- F: 15.000 mm
- C1: 0.600 mm
- h: 6.000 mm
- m: 6.000 mm
- Grease Nipple Size: NIP-B6
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 1 In Stock
Ships today if ordered in the next 9 hours and 41 minutes.
