NTN UCF212D1 4-BOLT SQUARE FLANGED UNIT
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: UCF212D1
IMS Product Code: 2125817
Packaging: Sold Individually
Description:
NTN UCF212D1 4-Bolt Square Flanged Unit
4-Bolt Square Flanged Unit with 60 mm bore diameter, cast iron housing, and set screw locking device.
Specifications
- Bearing Type: Ball Bearing
- Locking Device: Set Screw
- Seal Type: Contact
- Seal Material: Nitrile Rubber
- Bearing Number: UC212D1
- Housing Number: F212D1
- Housing Material: Cast Iron
- Housing Construction: 1 Piece
- Dynamic Load Rating: 52500 N
- Static Load Rating: 36000 N
- Rotational Speed [Max]: 2500.0 RPM
- Weight: 4.030 kg
- Operating Temperature Range: -40 to 120 degrees C
- Lubrication: Relubricatable
- d: 60.000 mm
- L: 175.0 mm
- J: 143.0 mm
- A: 48.0 mm
- A0: 68.700 mm
- A1: 18.0 mm
- A2: 29.0 mm
- N: 19.0 mm
- B: 65.100 mm
- S: 25.400 mm
- F: 6.200 mm
