NTN UCFC213 FLANGE BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: UCFC213
IMS Product Code: 1803678
Packaging: Sold Individually
Description:
NTN UCFC213 Flange Ball Bearing
Four-Bolt Piloted Flange Ball Bearing Unit - 65 mm Bore, Cast Iron Housing, Set Screw Locking, Non-Expansion Bearing
Specifications
- Bearing Type: Pillow Block
- Bore Diameter: 65 mm
- Outside Diameter: 120 mm
- Width: 31 mm
- Weight: 2.4 kg
- Product Type: Flange-Mount Ball Bearing Units
- Housing Material: Cast Iron
- Duty Type: Standard Duty
- Bolt Circle Diameter: 170 mm
- Locking Device: Set Screw
- Expansion Type: Non-Expansion Bearing (Fixed)
- Seal Type: Contact Seal with Flinger
- Overall Length Diameter: 205 mm
- Lubrication Type: Relubricatable
- Bore Type: Straight
- Radial Dynamic Load Capacity: 5850 kgf
- Radial Static Load Capacity: 4100 kgf
- Length Through Bore: 65.1 mm
- Pilot Diameter: 145 mm
- Unit Standoff: 55.7 mm
- Bolt Size: M16
- Series: UCFC200
- Replacement Bearing: UC213
- Type Of Bearing: Ball
- Mounting Type: 4-Bolt Piloted Flange
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 1 In Stock
Ships today if ordered in the next 15 hours and 14 minutes.
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 1 In Stock
Ships today if ordered in the next 15 hours and 14 minutes.
