NTN UCP206D1 PILLOW BLOCK BALL BEARING UNIT
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: UCP206D1
IMS Product Code: 2086853
Packaging: Sold Individually
Description:
NTN UCP206D1 Pillow Block Ball Bearing Unit
Pillow Block Ball Bearing Unit - 2-Bolt Base, 30 mm Bore, Cast Iron Material, Light Duty
Specifications
- Bearing Type: Ball Bearing
- Locking Device: Set Screw
- Seal Type: Contact
- Seal Material: Nitrile Rubber
- Bearing Number: UC206D1
- Housing Number: P206D1
- Housing Material: Cast Iron
- Housing Construction: 1 Piece
- Performance: Light Duty
- Dynamic Load Rating: 4400 lbf/19500 N/19.50 kN
- Static Load Rating: 2540 lbf/11300 N/11.30 kN
- Rotational Speed [Max]: 4900 RPM
- Weight: 2.950 lb/1.339 kg
- Operating Temperature Range: -40 to 250 ºF/-40 to 120 ºC
- Lubrication: Relubricatable
- d: 1.1811 in/30.000 mm
- J: 4.7500 in/121.0 mm
- L: 6.5000 in/165.0 mm
- A: 1.8750 in/48.0 mm
- H: 1.6875 in/42.9 mm
- H1: 0.6562 in/17.0 mm
- H2: 3.2812 in/83.0 mm
- L1: 2.1250 in/54.0 mm
- N: 0.6562 in/17.0 mm
- N1: 0.7812 in/20.0 mm
- B: 1.5000 in/38.100 mm
- S: 0.6260 in/15.900 mm
- F: 0.1811 in/4.600 mm
- Series: UCP2
- Bore Diameter: 30 mm
- Bolt Center-to-Center Length: 121 mm
- Base to Bore Centerline: 42.9 mm
- Overall Length: 165 mm
- Overall Width: 48 mm
- Overall Height: 83 mm
- Mounting Type: 2-Bolt Base
- Bore Type: Round
- Base Width: 48 mm
- Load Capacity: 19500 N Dynamic/11300 N Static
- Temperature Rating: -40 to 120 deg C
- Maximum Speed: 4900 rpm
- Material: Cast Iron
- Country of Origin: JP
- Harmonization Code: 8483.20.8040
- Radial Dynamic Load Capacity: 4400 lbf
- Radial Static Load Capacity: 2540 lbf
- Max Rpm: 4900 rpm
- Lubrication Type: Relubricatable
- End Type: Open
- Number Of Mounting Holes: 2
