NUMATICS 0FCRN FLOW CONTROL VALVE
Quick Overview
Manufactured By: NUMATICS
Manufacturer Part Number: 0FCRN
IMS Product Code: 1804989
Packaging: Sold Individually
Description:
Numatics 0FCRN Flow Control Valve
Pneumatic flow control valve with 10-32 UNF ports, 175 psi max pressure, 160F max temperature, anodized aluminum body
Specifications
- Type: Meter Out
- Port Size: 10-32 Unified NPT
- Options: Screw
- Temperature Range: 0F-160F
- Maximum Operating Pressure: 175PSI (12) Bar
- Body: Anodized Aluminum
- Cartridge: Nickel-Plated Brass
- Screw: Stainless Steel
- Spring: Stainless Steel
- Seals: Buna-N
- Valve Inlet Port: 10-32 UNF
- Valve Outlet Port: 10-32 UNF
- Valve Max. Pressure Rating: 175 psi
- Max. CFM - Valves: 3 cfm
- Pressure Range: 0 to 175 psi
- Max. Temp.: 160 Degrees F
- Rotation: 360 Degrees
- Speed Adjustment: Screwdriver
- Length: 8/9 in
- Width: 31/50 in
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
