OMRON E2E-X14MD1-M1 PROXIMITY SENSOR
Quick Overview
Manufactured By: OMRON
Manufacturer Part Number: E2E-X14MD1-M1
IMS Product Code: 2140268
Packaging: Sold Individually
Description:
Omron E2E-X14MD1-M1 Proximity Sensor
DC 3-wire proximity sensor with 14mm sensing distance and M12 connector
Specifications
- Sensing Distance: 14mm
- Output Type: DC 3-wire
- Connection Type: M12 Connector
- Shielded: Yes
- Operating Voltage: 12-24VDC
- Current Consumption: 15mA max.
- Output Current: 100mA max.
- Response Frequency: 1kHz
- Operating Temperature: -25 to 70 degrees C
- Storage Temperature: -40 to 85 degrees C
- Insulation Resistance: 50Mohm min.
- Dielectric Strength: 1000VAC 50/60Hz 1min.
- Vibration Resistance: 10-55Hz 1.5mm amplitude
- Shock Resistance: 1000m/s^2 (approx. 100G)
- Protection Structure: IEC IP67
- Material: PBT (Polybutylene Terephthalate)
- Weight: Approx. 65g
- Detection Head Size: M30
- Head Size Length: 62mm
- Power Supply Type: DC
- Output Mode: NPN
- Operation Mode: NO
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 5 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
