OPTEX UQ1-01 HIGH SPEED LASER MEASUREMENT CONTROLLER FOR THE CD5
Starting At: $715.40
Quick Overview
Manufactured By: OPTEX
Manufacturer Part Number: UQ1-01
IMS Product Code: 1781518
Packaging: Sold Individually
Description:
Optex UQ1-01 High Speed Laser Measurement Controller for the CD5 Series
The UQ1-01 designed for the CD5 Series gets measured data from the sensor automatically and updates calculation result and control output in 100 microseconds. The process is done in the unit itself so there is no load on the PLC
2 laser heads can be connected to one controller. The UQ1 has its own microprocessor and digital outputs and is independent of scan time of the PLC.
The UQ1 Series is recognized simply by placing the controller on the Melsec Q series base. No communication setup is required There is also no communication setup between the CD5/CD33 sensor and the UQ1 controller.
Multiple UQ1 cards and be be connected onto the Melsec Q bus. The cards have an infrared port for communication between the cards. This communication part allows for more complicated and high speed calculations when using multiple laser heads. For example 4 laser heads could be positioned looking at a part and checking for level.
Specifications:
| Features | Use with Mitsubishi PLC MELSEC-Q Series. Occupies 32 I/O points and receives measurement data from the sensor automatically and updates calculation result and control output with no extra load on the CPU. |
| Operation Temperature | -10° to +55° C |
| Set-Up | Once the UQ1 module is installed the CPU automatically recognizes the module and the sensors attached - no set-up procedure is required |
| Sampling Period | 100µs |
| Sensor Baud Rate | 921.6kbps |
| Control Input | 2ch NPN |
| Control Output | 2ch NPN |
| Output Voltage (Current) | 12-24VDC (80mA) |
