ORIENTAL MOTOR 4RK25GN-AW2TU REVERSIBLE MOTOR
Quick Overview
Manufactured By: ORIENTAL MOTOR
Manufacturer Part Number: 4RK25GN-AW2TU
IMS Product Code: 2174861
Packaging: Sold Individually
Description:
Oriental Motor 4RK25GN-AW2TU Reversible Motor
A reversible motor with a built-in friction brake at the back, ideal for applications where rotation direction changes frequently.
Specifications
- Motor Type: Reversible
- Frame Size: 3.15 in / 80 mm
- Output Power: 25 W (1/30 HP)
- Voltage (VAC): Single-Phase 110/115 VAC
- Frequency (Hz): 60
- Current: 0.56 A
- Shaft/Gear Type: Pinion Shaft (Gearhead required - sold separately)
- Type: Terminal Box
- Electromagnetic Brake: Not Equipped
- RoHS Compliant: Yes
- Safety Standards: UL CSA CCC EN CE
- CE Marking: Low Voltage Directives
- Insulation Resistance: 100 MO or more when 500 VDC megger is applied between the windings and the frame after rated motor operation under normal ambient temperature and humidity.
- Dielectric Strength: Sufficient to withstand 1.5 kV at 50 Hz or 60 Hz applied between the windings and the frame for 1 minute after rated motor operation under normal ambient temperature and humidity.
- Temperature Rise: 144�F (80�C) or less measured by the resistance change method after rated motor operation with connection to gearhead.
- Insulation Class: Class B (266�F [130�C])
- Overheat Protection: Built-in thermal protector (Automatic return type). Operating temperature, open: 266�F � 9�F (130�C � 5�C) close: 185�F � 36�F (85�C � 20�C)
- Ambient Temperature Range: 14�F ~ 104�F (-10�C ~ 40�C) (nonfreezing)
- Ambient Humidity: 85% maximum (noncondensing)
- Degree of Protection: IP40
