ORIENTAL MOTOR PK243-01BA-C16 STEPPER MOTOR
Quick Overview
Manufactured By: ORIENTAL MOTOR
Manufacturer Part Number: PK243-01BA-C16
IMS Product Code: 1791412
Packaging: Box of 30
Box of 10
Box of 30
Description:
Oriental Motor PK243-01BA-C16 Stepper Motor
Stepper motor, 2-phase, bipolar/unipolar configuration.
Specifications
- Brand: Oriental Motor
- Model: Vexta PK243-01BA-C16
- Country of Origin: Japan
- Rated Current per Phase: 0.67(bipolar) 0.95(Uni polar)
- Current Type: DC
- Wiring Configuration: 4-Wire Bipolar/Uni polar
- Insulation Class: B (Max 266 degrees F)
- Full Step Angle: 1.8 degrees (200 Steps)
- Holding Torque: 22oz-in(Unipolar)-28oz-in(Bipolar)
- Nominal Rated Input Voltage: 5.6V(Bipolar)- 4V(Uni polar)
- Resistance per Phase: 8.4O(Bipolar)-4.2O(Uni polar)
- Weight: 1 lbs
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 3 In Stock
Ships today if ordered in the next 8 hours and 26 minutes.
