PANASONIC MFDLNB3SG AC SERVO DRIVE
Starting At: $2,301.00
Quick Overview
Manufactured By: PANASONIC
Manufacturer Part Number: MFDLNB3SG
IMS Product Code: 1970401
Packaging: Sold Individually
Description:
Panasonic MFDLNB3SG AC Servo Drive, Analog/pulse - Panasonic (A6 Series - F-frame - Basic Type) - Three Phase Input - Supply Voltage 200VAC - Rated Output Current 120A
Specifications:
- Functions:
(Control method) IGBT PWM Sinusoidal wave drive
Built-in regenerative resistor (external resistor can also be connected)
Built in dynamic brake
Position control
Speed control
Combined position/speed control - Type of network: Three phase input
- Analog outputs: 2 x analog monitor outputs
- Digital inputs:
10 x control signal inputs
1 x Photo-coupler pulse signal input
1 x line receiver pulse signal input - Digital outputs:
6 x control signal outputs
3x line driver pulse signal output
1 x open collector pulse signal output - Operating mode: analog/pulse
Direct From Manufacturer:
A new product, shipped directly from the manufacturer.
Lead Time: 3 to 30 Days
