PANASONIC SF4B-H96-01<V2> SAFETY LIGHT CURTAIN
Quick Overview
Manufactured By: PANASONIC
Manufacturer Part Number: SF4B-H96-01
IMS Product Code: 1870656
Packaging: Box of 2
Sold Individually
Box of 2
Description:
Panasonic SF4B-H96-01<V2> Safety Light Curtain
Safety Light Curtain Type 4 with 96 beams, 1910mm protective height, ø25mm minimum sensing object
Specifications
- Min. sensing object: ø25 mm
- No. of beam channels: 96
- Protective height: 1,910 mm
- Operating range: 0.3 to 7 m
- Response time: OFF response: 14 ms or less, ON response: 80 to 90 ms
- Supply voltage: 24 V DC ±10 %
- Current consumption: Emitter: 120 mA or less, Receiver: 200 mA or less
- Control outputs (OSSD): PNP/NPN open-collector transistor
- Protection structure: IP65, IP67
- Ambient temperature: -10 to +55 degrees C
- Material: Enclosure: Aluminium, Upper and lower edges: Iron, Sensing surface: Polycarbonate/Polyester resin, Cap: PBT
- Degree of protection: IP65, IP67
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 4 In Stock
Ships today if ordered in the next 16 hours and 12 minutes.
