PEPPERL+FUCHS 108993 THRU-BEAM SENSOR
Quick Overview
Manufactured By: PEPPERL & FUCHS
Manufacturer Part Number: 108993
IMS Product Code: 2155776
Packaging: Sold Individually
Description:
Pepperl+Fuchs 108993 Thru-Beam Sensor
Thru-beam photoelectric sensor with NAMUR output and M12 connector
Specifications
- Effective detection range: 0 ... 10 m
- Threshold detection range: 10 m
- Light source: LED
- Light type: modulated visible red light, 660 nm
- MTTFd: 575 a
- Mission Time (TM): 20 a
- Diagnostic Coverage (DC): 0 %
- Function indicator: LED yellow: switching state (receiver)
- Control elements: sensitivity adjustment
- Operating voltage: 6 ... 15.5 V DC (Ri ˜ 0 Ohm)
- Switching type: light/dark on, programmable
- Signal output: 1 NAMUR output NC/NO programmable
- Degree of protection: IP67
- Connection: V1 connector (M12 x 1), 4-pin, rotatable through 90°
- Housing: PBT
- Optical face: scratch resistant plastic lens
- Dimensions: 1.0 in x 1.0 in x 1.0 in (2.5 cm x 2.5 cm x 2.5 cm)
- Weight: 1 lbs 0.0 oz (0.5 kg)
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
