PEPPERL & FUCHS NBB2-8GM30-E2 INDUCTIVE PROXIMITY SENSOR
Quick Overview
Manufactured By: PEPPERL & FUCHS
Manufacturer Part Number: NBB2-8GM30-E2
IMS Product Code: 2154367
Packaging: Sold Individually
Description:
Pepperl & Fuchs NBB2-8GM30-E2 Inductive Proximity Sensor
Inductive proximity sensor with PNP output, 2 mm sensing distance, 8 mm diameter x 30 mm length, flush mount, brass housing, PVC cable connection.
Specifications
- Switching function: Normally open (NO)
- Output type: PNP
- Rated operating distance: 2 mm
- Installation: flush
- Assured operating distance: 0 ... 1.62 mm
- Nominal ratings Operating voltage: 5 ... 30 V
- Switching frequency: 0 ... 6000 Hz
- Hysteresis: typ. 5%
- Operating current: 0 ... 100 mA
- Off-state current: 0 ... 0.2 mA
- No-load supply current: = 10 mA
- Time delay before availability: = 100 ms
- Switching state indicator: LED, yellow
- Ambient temperature: -40 ... 85 degrees C
- Storage temperature: -40 ... 85 degrees C
- Connection type: cable
- Housing material: brass, nickel-plated
- Sensing face: LCP
- Degree of protection: IP65 / IP66 / IP67
- Cable diameter: 3.5 mm ± 0.1 mm
- Bending radius: > 10 x cable diameter
- Material: PVC
- Color: black
- Number of cores: 3
- Core cross section: 0.14 mm2
- Length: 2 m
- Dimensions Length: 30 mm
- Diameter: 8 mm
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 1 In Stock
Ships Tomorrow
