PEPPERL+FUCHS NBB20-L3M-A2-C3-V1 INDUCTIVE PROXIMITY SENSOR
Quick Overview
Manufactured By: PEPPERL & FUCHS
Manufacturer Part Number: NBB20-L3M-A2-C3-V1
IMS Product Code: 2001990
Packaging: Sold Individually
Description:
Pepperl+Fuchs NBB20-L3M-A2-C3-V1 Inductive Proximity Sensor
Inductive proximity sensor with PNP output and 20 mm sensing distance.
Specifications
- Switching Function: complementary
- Output Type: PNP
- Rated Operating Distance: 20 mm
- Installation: flush
- Operating Voltage: 10 ... 30 V DC
- Switching Frequency: 0 ... 5 Hz
- Hysteresis: typ. 5 %
- Operating Current: 0 ... 200 mA
- Connection Type: Connector plug M12 x 1 , 4-pin
- Housing Material: GD-ZnAl4Cu1
- Sensing Face: Duroplast
- Degree of Protection: IP67
- Dimensions: 67 mm L x 40 mm W x 40 mm H
