PEPPERL & FUCHS NBB4-12GM50-E2-V1 INDUCTIVE PROXIMITY SENSOR
Quick Overview
Manufactured By: PEPPERL & FUCHS
Manufacturer Part Number: NBB4-12GM50-E2-V1
IMS Product Code: 2011200
Packaging: Sold Individually
Description:
Pepperl & Fuchs NBB4-12GM50-E2-V1 Inductive Proximity Sensor
Inductive proximity sensor with PNP output, 4 mm sensing range, M12 threaded housing, brass construction with white bronze coating.
Specifications
- Switching Function: Normally open (NO)
- Output Type: PNP
- Rated Operating Distance: 4 mm
- Installation: Flush
- Assured Operating Distance: 0 ... 3.24 mm
- Operating Voltage: 6 ... 36 V
- Switching Frequency: 0 ... 2550 Hz
- Hysteresis: typ. 5%
- Operating Current: 0 ... 200 mA
- Connection Type: Connector plug
- Housing Material: Brass, white bronze coated
- Sensing Face: PBT, green
- Degree of Protection: IP65 / IP66 / IP67 / IP68
- Threading: M12 x 1
- Number of Pins: 3
- Length: 64.5 mm
- Diameter: 12 mm
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
