PHOENIX CONTACT 1803617 PCB TERMINAL BLOCK
Quick Overview
Manufactured By: PHOENIX CONTACT
Manufacturer Part Number: 1803617
IMS Product Code: 1734692
Packaging: Sold Individually
Description:
Phoenix Contact 1803617 PCB Terminal Block
6-position PCB terminal block with screw connection, 3.81mm pitch, green housing
Specifications
- Connection Type: Screw
- Color: Green
- AWG Range: 28 - 16 AWG
- No. of Positions: 6
- Rated Current: 8A
- Rated Voltage: 160V
- Pitch (Spacing): 3.81 mm
- Height: 11.1 mm
- Width: 23.65 mm
- Type: Terminal Block
- Gender: F
- Number of Contacts: 6
- Terminal Pitch (mm): 3.81
- Number of Rows: 1
- Number of Circuits: 6
- Termination Method: Screw
- Body Orientation: Right Angle
- Maximum Current Rating (A): 8
- Maximum Voltage Rating: 160V
- Minimum Operating Temperature: -40 degrees C
- Maximum Operating Temperature: 100 degrees C
- Product Length (mm): 23.65
- Product Depth (mm): 16.1
- Product Height (mm): 11.1
- Housing Color: Green
- Mounting: Cable Mount
