PHOENIX CONTACT SACC-M12FSB-5CON-PG9-SH-AU M12 CONNECTOR
Quick Overview
Manufactured By: PHOENIX CONTACT
Manufacturer Part Number: SACC-M12FSB-5CON-PG9-SH-AU
IMS Product Code: 1807368
Packaging: Sold Individually
Description:
Phoenix Contact SACC-M12FSB-5CON-PG9-SH-AU M12 Connector
M12 data connector with 5 positions, shielded, straight socket, B-coding, screw connection, Pg9 cable gland
Specifications
- Application: Data
- Sensor type: PROFIBUS
- Number of positions: 5
- Shielded: yes
- Coding: B
- Cable outlet: straight
- Pg screw connection: Pg9
- Outside diameter: 6.5 mm ... 8.5 mm
- Material of grip body: Zinc die-cast, nickel-plated
- Contact material: CuZn
- Contact surface material: Au
- Connection method: Screw connection
- Connection cross section: 0.25 mm˛ ... 0.75 mm˛ (without ferrule)
- Tightening torque: 0.4 Nm (M12 knurl)
- Nominal voltage UN: 48 V AC
- Nominal current IN: 4 A
- Degree of protection: IP67
- Ambient temperature (operation): -40 degrees C ... 85 degrees C (Plug / socket)
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships on Monday, May 11, 2026
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
