PHOENIX CONTACT SACC-M12MSB-5CON-PG9-SH-AU BUS SYSTEM CONNECTOR
Quick Overview
Manufactured By: PHOENIX CONTACT
Manufacturer Part Number: SACC-M12MSB-5CON-PG9-SH-AU
IMS Product Code: 1807354
Packaging: Sold Individually
Description:
Phoenix Contact SACC-M12MSB-5CON-PG9-SH-AU Bus System Connector
Specifications:
- Rated current at 40°C: 4 A
- Rated voltage: 60 V DC 48 V AC
- Number of positions: 5
- Insulation resistance: ≥ 100 MΩ Coding B - inverse
- Standards/regulations: M12 connector IEC 61076-2-101
- Signal type/category: PROFIBUS INTERBUS
- Status display: No
- Overvoltage category: II
- Degree of pollution: 3
- Connection method: Screw connection
- Conductor cross section:
- 0.25 mm² ... 0.75 mm² (without ferrule)
- 0.14 mm² ... 0.75 mm² (with ferrule)
- 0.25 mm² ... 0.75 mm² (solid)
- Conductor cross section AWG:
- 24 ... 18 (without ferrule)
- 26 ... 20 (with ferrule)
- Insertion/withdrawal cycles: ≥ 100
- Torque;
- 0.4 Nm (M12 knurl)
- 0.2 Nm (Screw terminal blocks)
- 0.8 Nm ... 1 Nm (Pressure nut with 4 mm ... 8 mm external cable diameter)
- 1 Nm ... 1.4 Nm (Pressure nut with 8 mm ... 12 mm external cable diameter)
- Tightening torque: Screw plug insert with sleeve housing as far it will go
- Assembly instructions: The wires can be connected both with ferrules and without ferrules
