ROCKWELL AUTOMATION 2094-BM02-S AXIS MODULE
Quick Overview
Manufactured By: ROCKWELL AUTOMATION
Manufacturer Part Number: 2094-BM02-S
IMS Product Code: 2148708
Packaging: Sold Individually
Description:
Rockwell Automation 2094-BM02-S Axis Module
400VAC class Axis Module with continuous current of 10.3 A and peak current of 25.8 A. It has an efficiency of 98% and short-circuit current rating of 200,000 A (rms) symmetrical and integrated Safe Torque-off feature.
Specifications
- Module Type: Axis Module
- Voltage: 400/460V
- Continuous Output Current: 10.3 A
- Peak Current: 25.8 A
- Efficiency: 98%
- Short Circuit Current Rating: 200,000 A (rms) symmetrical
- Safe Torque Off: Integrated
- Internal Shunt Resistor: 115 Ohms
- Continuous Power Out (nom): 6.6 kW
- Voltage Class: 400V
- Nom Drive Voltage: 360-480 Volts (3 Phase)
- Internal Shunt Continuous Power: 50 W
- Internal Shunt Peak Power: 5.6 kW
- Capacitance: 270 uF
- Series: Kinetix 6000
- Drive Type: Multi-Axis Servo Drive
- Input Voltage: 460 Volts
- Heat Dissipation: 93 Watts
- Brake Current Value: 1 or 3 Amps
- Weight: 5.6 pounds (2.54 kilograms)
