ROSS Y1523C6002 MANUAL PNEUMATIC LOCKOUT VALVE
Quick Overview
Manufactured By: ROSS
Manufacturer Part Number: Y1523C6002
IMS Product Code: 1991925
Packaging: Sold Individually
Description:
Ross Y1523C6002 Manual Pneumatic Lockout Valve
Manual pneumatic lockout valve with 1" inlet/outlet and 1-1/4" exhaust ports.
Specifications
- Series: 15 Series Classic
- Actuation: Manual
- Function: 3/2
- Construction: Spool
- Valve Body Material: Cast Aluminum
- Thread Type: NPT
- Inlet Size: 1
- Outlet Size: 1
- Exhaust Size: 1-1/4"
- Body Size: 1
- Mounting: In-line
- Length: 7.72 in (196 mm)
- Width: 2.36 in (59.8 mm)
- Height: 10.76 in (273 mm)
- Weight: 3.0 lbs
- Ports 1-2 Flow: 17 Cv (17000 Nl/min)
- Ports 2-3 Flow: 9.5 Cv (9300 Nl/min)
- Ambient Temperature: 40 to 175 F (4 to 80 C)
- Media Temperature: 40 to 175 F (4 to 80 C)
- Fluid Media: Filtered Air
- Operating Pressure: 0 to 300 psig (0 to 20.7 bar)
- Poppet/Spool Material: Stainless Steel
- Seal Material: Fluorocarbon
- Safety Category: Category 1
- PL Rating: PL c
- EAC Declaration: Yes
