SCHMERSAL AZM200-B30-RTAG1P20 SAFETY INTERLOCK SWITCH
Quick Overview
Manufactured By: SCHMERSAL
Manufacturer Part Number: AZM200-B30-RTAG1P20
IMS Product Code: 2159867
Packaging: Sold Individually
Description:
Schmersal AZM200-B30-RTAG1P20 Safety Interlock Switch
Electromagnetic safety interlock with RFID coding and power-to-lock functionality. Features high tamper protection, integrated LED status indicators, and suitable for series connection.
Specifications
- Type: Electromagnetic safety interlock with RFID coding
- Locking Type: Power-to-lock
- Coding: High-level RFID coded actuator (RTAG1P20)
- Actuation: Non-contact, no mechanical wear
- Safety Outputs: 2 OSSD outputs
- Enclosure Protection: IP69K
- Housing Material: Thermoplastic
- Mounting: Universal design for flexible positioning
- Series: AZM200
- Rated Actuation Distance: 30mm
- Approach Direction: Front
- Coding: Individual coding
- Guard Locking: Yes
- Manual Release: Yes
- Cable Entry: M20 x 1.5
- Connection Type: Cable
- Cable Length: 2m
- Number of Conductors: 5
- Conductor Cross-Section: 0.34mm�
- Rated Voltage: 24VDC
- Rated Current: 100mA
- Switching Frequency: 1Hz
- Ambient Temperature: -25�C to +60�C
- Protection Class: IP67
- Weight: approx. 340g
