SCHMERSAL ZFH 232-11 FOOT SWITCH
Quick Overview
Manufactured By: SCHMERSAL
Manufacturer Part Number: ZFH232-11
IMS Product Code: 2068540
Packaging: Sold Individually
Description:
Schmersal ZFH 232-11 Foot Switch
Aluminium foot switch with protective shield, 1 NO and 1 NC contact, screw terminals M20 x 1.5, IP65 protection
Specifications
- Standards: BG-GS-ET-15, DIN VDE 0660-200, EN IEC 60947-5-1
- Housing material: Aluminium
- Housing coating material: powder-coated
- Material of the housing cover: Aluminium
- Material of the pedal: Glass-fibre, reinforced thermoplastic
- Material of the protective shield: Aluminium
- Colour of the housing: RAL 9006 (White aluminum)
- Protective shield: Yes
- Probing possible: Yes
- Number of normally closed (NC): 1
- Number of normally open (NO): 1
- Mechanical lifetime, minimum: 1,000,000 Operations
- Termination: Screw terminals M20 x 1.5
- Cable section, maximum: 1 x 2.5 mm
- Width: 170 mm
- Height: 189 mm
- Depth: 274 mm
- Degree of protection: IP65
- Ambient temperature: -25 ... +70 degrees C
- Rated insulation voltage Ui: 500 V
- Rated impulse withstand voltage Uimp: 6 kV
- Thermal test current: 10 A
- Utilisation category AC-15: 230 VAC, 4 A
- Utilisation category DC-13: 24 VDC, 1 A
- Switching element: NO contact, NC contact
- Switching principle: Snap action
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 3 In Stock
Ships today if ordered in the next 13 hours and 18 minutes.
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 3 In Stock
Ships today if ordered in the next 13 hours and 18 minutes.
