SCHNEIDER AUTOMATION INC TSXDSY08T22 DISCRETE OUTPUT MODULE
Quick Overview
Manufactured By: SCHNEIDER AUTOMATION INC
Manufacturer Part Number: TSXDSY08T22
IMS Product Code: 1844651
Packaging: Sold Individually
Description:
Schneider Automation Inc TSXDSY08T22 Discrete Output Module
Discrete output module with 8 solid-state protected outputs, 24 V DC, 2 A.
Specifications
- Discrete output number: 8
- Discrete output type: Solid state protected
- Discrete output voltage: 24 V DC positive conforming to EN/IEC 61131-2 19...30 V
- Discrete output current: 2 A
- Current per channel: <= 2.5 A
- Current per module: <= 14 A
- Leakage current: < 1 mA at state 0
- [Ures] residual voltage: < 0.5 V
- Response time: 0.2 ms
- Switching frequency: 0.5/LI² Hz
- Output overvoltage protection: By transil diode
- Reverse polarity protection: Reverse mounted diode
- Output overload protection: Electronic tripping on reactivation
- Short-circuit protection: Electronic tripping on reactivation
- Preactuator voltage detection threshold: 16 V
- Load impedance: >= 12 W
- Isolation resistance: > 10 MOhm 500 V
- Power dissipation: (1.3 W + 0.2 W x No of outputs x current per module)
- Electrical connection: Screw terminal block
- Current consumption: 55 mA 5 V DC
- Module format: Standard
- Ambient air temperature for operation: 0...60 degrees C
- Ambient air temperature for storage: -25...70 degrees C
- Relative humidity: 10...95 % without condensation for operation 5...95 % without condensation for storage
- Operating altitude: 0...2000 m
- Protective treatment: TC
- IP degree of protection: IP20
- Pollution degree: 2
- Weight: 0.41 kg
- Dimensions: 17.00 × 6.00 × 7.00 cm
