More Views
SCHNEIDER ELECTRIC LC2D40AG7 REVERSING CONTACTOR
Quick Overview
Manufactured By: SCHNEIDER ELECTRIC
Manufacturer Part Number: LC2D40AG7
IMS Product Code: 2117183
Packaging: Sold Individually
Description:
Schneider Electric LC2D40AG7 Reversing Contactor
Reversing contactor with 3 poles, 40A maximum load current, 120/690V DC coil voltage.
Specifications
- Coil Power Rating: 13/16 VA
- Coil Voltage: 300 V DC, 120v50/60Hz AC
- Contact Rating: 10/60 A at 440 V AC
- Dimensions: 120 mm W x 119 mm D x 122 mm H
- Enclosure Type: IP2X
- Operating Cycles: 3600 cycles/hr
- Operating Temperature: -5 to 60/-40 to 70 degrees C
- Series: LC2D
- Terminal Type: Screw Clamp
- Type: Mechanical Standard, Reversing Contactor
- Wattage: 2.4/5.4 W
- Mounting Type: Rail/Surface
- Power Factor: 0.75 Inrush, 0.3 Hold-In
- Inductive AC-3 (A): 40
- Resistive AC-1 (A): 60
- Rated Insulation Voltage (Vi): 690v UL/CSA
- Rated Impulse Withstand Voltage (Vimp): 8kV
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 2 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
