SCHNEIDER ELECTRIC LRD3322 THERMAL OVERLOAD RELAY
Quick Overview
Manufactured By: SCHNEIDER ELECTRIC
Manufacturer Part Number: LRD3322
IMS Product Code: 1837023
Packaging: Sold Individually
Description:
Schneider Electric LRD3322 Thermal Overload Relay
3-pole thermal overload relay with 17-25A current rating, 600/1000VAC voltage rating, 1NO/1NC contact configuration, and screw clamp terminals. Used with LC1D40-LC1D95 contactors.
Specifications
- Type: Thermal overload relay
- Series: TeSys Deca
- Amperage: 17-25
- Voltage: 600/1000VAC
- Poles: 3
- Phase: 3
- Mounting Type: Din Rail
- Contact Configuration: 1NO, 1NC
- Trip Class: 10
- Reset: Manual or Automatic
- Terminals: Screw Clamp
- Temperature Rating: -20 to 60 degrees C
- Dimensions: 4.52 in L x 2.75 in W x 3.19 in H
- Protection: Thermal
- Standards: EN/IEC 60947-4-1, UL 508, CSA C22.2 No 14
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
