SECO 23941, CCMX08T308 E07 T25M GRADE CARBIDE MILLING INSERT
Quick Overview
Manufactured By: SECO TOOLS
Manufacturer Part Number: 23941
IMS Product Code: 1791096
Packaging: Sold Individually
Description:
Seco 23941, CCMX08T308 E07 T25M Grade Carbide Milling Insert
Specifications:
| Insert Style | CCMX |
| Insert Size | 08T308 |
| Material | Carbide |
| Material Grade | C5 |
| Manufacturer's Grade | T25M |
| Coating | TiC/TiCN/TiN |
| Width | 0.3160 |
| Length | 0.2600 |
| Inscribed Circle | 0.3160 |
| Thickness | 0.1730 |
| Corner Radius (Decimal Inch) | 0.0310 |
| Hole Diameter (Decimal Inch) | 0.1100 |
| Relief Angle | 7 |
| Rake Angle | 15 |
| Coating Process | CVD |
| Included Angle | 80 |
| Shape | Diamond |
| Insert Hand | Right Hand |
| Chipbreaker | E07 |
| ISO Number | CCMX08T308-E07 |
