SICK C4C-SB12030A10000 SAFETY LIGHT CURTAIN
Quick Overview
Manufactured By: SICK
Manufacturer Part Number: C4C-SB12030A10000
IMS Product Code: 2147266
Packaging: Sold Individually
Description:
Sick C4C-SB12030A10000 Safety Light Curtain
Safety light curtain transmitter with 30 mm resolution, PL e, SIL 3, type 4 safety level, 1,200 mm protective field height, and 12.5 m scanning range. Features IP65, IP66, IP67, IP69K enclosure rating and 24VDC operating voltage.
Specifications
- Resolution: 30 mm
- Scanning Range: 12.5 m
- Protective Field Height: 1,200 mm
- Connection Type: Connecting cable, 15 m, flying leads, 5-wire
- Enclosure Rating: IP65, IP66, IP67, IP69K
- Safety Level: PL e, SIL 3, type 4
- Type: Sender
- Operating Voltage: 24VDC
- Response Time: <16ms
- Housing Material: Aluminum
- Operating Temperature: -10°C to +55°C
- Series: deTec
- Protection: Hand/Arm
- Detection Capability: 30mm
- Features: Transmitter Only
- Ingress Protection: IP65 - Dust Tight, Water Resistant
- Weight: 1.11 kg
- Country of Origin: Germany
- Approvals/Standards: CE, UKCA, cULus, ECOLAB, Diversey
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 13 hours and 49 minutes.
