SIEMENS 3RT2015-1AK61 CONTACTOR
Quick Overview
Manufactured By: SIEMENS
Manufacturer Part Number: 3RT2015-1AK61
IMS Product Code: 2163606
Packaging: Sold Individually
Description:
Siemens 3RT2015-1AK61 Contactor
3-pole contactor with 1 NO auxiliary contact, rated for 7A AC-3, 110V 50Hz/120V 60Hz coil voltage, DIN rail mounting, and screw termination.
Specifications
- Type: 3-Pole
- Mounting: DIN Rail
- Termination: Screw Termination
- Contact Voltage: 600 Vac
- Contacts: 1 NO
- Current: 7 Amps
- AC Operating Coil Voltage: 110V 50Hz / 120V 60Hz
- Three Phase HP Ratings at 230V: 2
- Three Phase HP Ratings at 460V: 3
- Auxiliary Contacts NO: 1
- Auxiliary Contacts NC: 0
- Frame Size: S00
- Amp Ratings AC3: 7
- Amp Ratings AC1: 18
- Maximum Horsepower Single Phase 115v HP: 0
- Maximum Horsepower Three Phase 230v HP: 2
- Maximum Horsepower Three Phase 460v HP: 3
- Maximum Current Inductive AC-3 (A): 7
- Maximum Current Resistive AC-1 (A): 18
- Number of Poles: 3
- Auxiliary Contacts N.O.: 1
- Auxiliary Contacts N.C.: 0
- Coil Voltage: 120V AC
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
