SKF 6001 JEM DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: SKF
Manufacturer Part Number: 6001JEM
IMS Product Code: 1924485
Packaging: Sold Individually
Description:
SKF 6001 JEM Deep Groove Ball Bearing
Open, single row deep groove ball bearing with straight bore, 12 mm ID, 28 mm OD, 8 mm width, C3 internal clearance, sheet metal cage, bearing steel material, uncoated.
Specifications
- Bore Type: Straight
- Bore Diameter: 12 mm
- Outside Diameter: 28 mm
- Overall Width: 8 mm
- Closure Type: Open
- Internal Clearance: C3
- Cage Type: Sheet metal
- Precision Rating: ABEC 3
- Bearing Material: Bearing steel
- Cage Material: Bearing steel
- Element Material: Bearing steel
- Fillet Radius: 0.3 mm
- Max Rpm: 38000 rpm
- Series: 60
- Radial Dynamic Load Capacity: 1210 lbf
- Radial Static Load Capacity: 530 lbf
- Weight: 0.06 lbs
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 15 hours and 17 minutes.
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 6 In Stock
Ships today if ordered in the next 15 hours and 17 minutes.
