SKF 6013 ZJEM DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: SKF
Manufacturer Part Number: 6013 ZJEM
IMS Product Code: 1838522
Packaging: Sold Individually
Description:
SKF 6013 ZJEM Deep Groove Ball Bearing
Deep Groove Ball Bearing, Straight Bore, 65 mm ID, 100 mm OD, 18 mm Width, Single Shielded, Without Snap Ring
Specifications
- Bore Type: Straight
- Bore Diameter: 65 mm
- Outside Diameter: 100 mm
- Overall Width: 18 mm
- Closure Type: Single Shielded
- Snap Ring Included: Without Snap Ring
- Internal Clearance: C3
- Cage Type: Sheet metal
- Precision Rating: ABEC 3
- Finish Coating: Uncoated
- Bearing Material: Bearing steel
- Cage Material: Bearing steel
- Max Rpm: 7000 rpm
- Series: 60
- Radial Dynamic Load Capacity: 7170 lbf
- Radial Static Load Capacity: 5620 lbf
- Weight: 0.98 lbs
- Seal Material: Tinplate
- Basic Dynamic Load Rating: 31.9 kN
- Basic Static Load Rating: 25 kN
- Limiting Speed: 12000 r/min
- Number of Rows: 1
- Reference Speed: 14000 r/min
- Sealing: Shield on one side
- Sealing Type: Non-contact
- SKF Performance Class: SKF Explorer
- Tolerance Class: Class P6 (P6)
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 15 hours and 14 minutes.
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 15 hours and 14 minutes.
