SKF 6218 2ZJ/EM DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: SKF
Manufacturer Part Number: 6218 2ZJEM
IMS Product Code: 1833225
Packaging: Sold Individually
Description:
SKF 6218 2ZJ/EM Deep Groove Ball Bearing
Deep groove ball bearing with shields on both sides, SKF Explorer performance class
Specifications
- Bore Type: Cylindrical
- Bore Diameter: 90 mm
- Outside Diameter: 160 mm
- Overall Width: 30 mm
- Closure Type: Double Shielded
- Internal Clearance: C3
- Cage Type: Sheet metal
- Precision Rating: ABEC 1
- Bearing Material: Bearing steel
- Cage Material: Bearing steel
- Seal Material: Tinplate
- Max Rpm: 4300 rpm
- Series: 62
- Radial Dynamic Load Capacity: 22706 lbf
- Radial Static Load Capacity: 16523 lbf
- Weight: 5.08 lbs
- Basic Dynamic Load Rating: 101 kN
- Basic Static Load Rating: 73.5 kN
- Limiting Speed: 4300 r/min
- Reference Speed: 8500 r/min
- Number of Rows: 1
- Sealing Type: Non-contact
- SKF Performance Class: SKF Explorer
