SKF 7301 BEP ANGULAR CONTACT BALL BEARING
Quick Overview
Manufactured By: SKF
Manufacturer Part Number: 7301 BEP
IMS Product Code: 1908640
Packaging: Sold Individually
Description:
SKF 7301 BEP Angular Contact Ball Bearing
Angular Contact Ball Bearing, 12 mm Bore, 37 mm OD, 12 mm Width, Open, 40 degrees Contact Angle
Specifications
- Bore Type: Straight
- Bore Diameter: 12 mm
- Outside Diameter: 37 mm
- Overall Width: 12 mm
- Row Type: Single-Row Non-Fill Slot
- Closure Type: Open
- Snap Ring Included: Without Snap Ring
- Duplex Type: Single
- Bearing Type: Angular Contact Bearings
- Contact Angle: 40 degrees
- Bearing Material: Steel
- Radial Dynamic Load Capacity: 10.6 kN
- Radial Static Load Capacity: 5 kN
- Cage Material: Nylon
- Inner Ring Width: 12 mm
- Element Material: Bearing steel
- Max Rpm: 24000 rpm
- Finish Coating: Uncoated
- Precision Rating: ABEC 3 (ISO Class 6)
- Fillet Radius: 1 mm
- Series: 73
- Weight: 0.14 lbs
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 13 hours and 20 minutes.
