SKF F4B 115-TF FLANGE-MOUNT BALL BEARING
Quick Overview
Manufactured By: SKF
Manufacturer Part Number: F4B 115-TF
IMS Product Code: 1846037
Packaging: Sold Individually
Description:
SKF F4B 115-TF Flange-Mount Ball Bearing
Flange-mount ball bearing unit with 1-15/16 in bore, 4-bolt flange mount, set screw locking, cast iron housing material, non-expansion bearing (fixed), standard duty, contact seal with flinger seal
Specifications
- Bolt Center To Center Length: 4.3750 in
- Bore Diameter: 1-15/16 in
- Length Through Bore: 60.6 mm
- Overall Length Diameter: 143 mm
- Weight: 5.27 lbs
- Bore Type: Straight
- Duty Type: Standard Duty
- Expansion Type: Non-Expansion Bearing (Fixed)
- Housing Material: Cast Iron
- Locking Device: Set Screw
- Lubrication Type: Relubricatable
- Max Rpm: 4000 rpm
- Mounting Type: 4-Bolt Flange
- Radial Dynamic Load Capacity: 7900 lbf
- Radial Static Load Capacity: 5220 lbf
- Seal Type: Contact Seal with Flinger
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 7 In Stock
Ships on Monday, September 21, 2026
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
