SMC CDQ2KB32-30DZ COMPACT CYLINDER
Quick Overview
Manufactured By: SMC
Manufacturer Part Number: CDQ2KB32-30DZ
IMS Product Code: 2153620
Packaging: Sold Individually
Description:
SMC CDQ2KB32-30DZ Compact Cylinder
Compact double-acting air cylinder with 32 mm bore diameter and 30 mm stroke length. Made of aluminum with through-hole mounting style.
Specifications
- Bore Diameter: 32 mm
- Stroke Length: 30 mm
- Cylinder Action: Double Acting
- Cylinder Type: Compact
- Mounting Style: Through Hole
- Body Material: Aluminum
- Body Material Finish: Anodized
- Rod Diameter: 14 mm
- Rod Thread Size: M8 x 1.25
- Piston Material: Aluminum
- Piston Material Finish: Chromate Coated
- Piston Rod Material: Carbon Steel
- Piston Rod Material Finish: Chrome Plated
- Maximum Operating Pressure: 145 MPa
- Minimum Operating Pressure: 7.25 MPa
- Maximum Operating Temperature: 140 degrees F
- Minimum Operating Temperature: 14 degrees F
- Overall Height: 45 mm
- Overall Width: 49.5 mm
- Weight: 326 g
- Rod Gender: Female
- Rod Rotation: Non-Rotating Rod
- Series: CQ2K
- For Fluid Type: Air
- Number of Rods: Single Rod
- Cushion Type: None
- Magnetic Piston: Magnetic Piston
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
