SMC IDG100-N04B-P MEMBRANE AIR DRYER
Quick Overview
Manufactured By: SMC
Manufacturer Part Number: IDG100-N04B-P
IMS Product Code: 1820348
Packaging: Sold Individually
Description:
SMC IDG100-N04B-P Membrane Air Dryer
Membrane air dryer for compressed air systems.
Specifications
- Fluid: Compressed air
- Inlet air pressure: 0.3 to 1.0 MPa
- Inlet air temperature: 5 to 50 degrees C
- Ambient temperature: 5 to 50 degrees C
- Outlet air atmospheric pressure dew point: -20 degrees C
- Inlet air flow rate: 1190 L/min (ANR)
- Outlet air flow rate: 1000 L/min (ANR)
- Purge air flow rate: 190 L/min (ANR)
- Dew point indicator purge air flow rate: 1 L/min (ANR) at 0.7 MPa
- Port size: 1/2
- Weight: 1.55 kg (with bracket: 1.70 kg)
- Style: Single unit style
- Thread Type: NPT
- Bore Size: 1/2
- Accessory: Bracket
- Semi-standard Specifications: With Fitting For Purge Air Discharge
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 2 In Stock
Ships today if ordered in the next 44 minutes.
