SMC MHF2-16D1R LOW PROFILE AIR GRIPPER
Quick Overview
Manufactured By: SMC
Manufacturer Part Number: MHF2-16D1R
IMS Product Code: 2136965
Packaging: Sold Individually
Description:
SMC MHF2-16D1R Low Profile Air Gripper
Pneumatic gripper with low profile design, double-acting, and parallel gripper type.
Specifications
- Bore Diameter: 16 mm
- Closed Width: 0 mm
- Finger Type: 2 Finger Low Profile (Middle Stroke)
- Gripper Type: Parallel
- Holding Force Closed: 90 N
- Holding Force Open: 90 N
- Maximum Operating Pressure: 102 psi
- Minimum Operating Pressure: 15 psi
- Open Width: 32 mm
- Operating Pressure Range: 15 psi to 102 psi
- Operating Temperature Range: 14 F to 140 F
- Overall Height: 33 mm
- Overall Length: 94 mm
- Overall Width: 50 mm
- Piston Action: Double-Acting
- Port Gender: Female
- Port Size: M5x0.8
- Series: MHF2
- Type: Pneumatic Gripper
- Weight: 1.05116 lb
- Country/Region of Manufacture: Japan
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 2 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
