SMC MHZL2-20D3 PARALLEL GRIPPER
Quick Overview
Manufactured By: SMC
Manufacturer Part Number: MHZL2-20D3
IMS Product Code: 2135147
Packaging: Box of 5
Sold Individually
Box of 5
Description:
SMC MHZL2-20D3 Parallel Gripper
Double-acting parallel air gripper with 20mm bore size, long stroke type. High rigidity and accuracy through integrated linear guide. Available with flat finger option. Double-acting operation with 18mm opening/closing stroke.
Specifications
- Action: Double acting
- Bore size (mm): 20
- Gripping force external (N): 42
- Gripping force internal (N): 66
- Opening/closing stroke (mm): 18
- Mass (g): 270
- Auto Switch: No switch
- Body Option: Basic Style
- Finger option: Flat Type
- Operating Pressure Range: 15 psi to 102 psi
- Overall Length: 90 mm
- Overall Width: 62 mm
- Overall Height: 27.6 mm
- Number of Fingers: 2
- Port Size: M5x0.8
- Series: MHZ2
- Country of Origin: Japan
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 2 In Stock
Ships today if ordered in the next 14 hours and 14 minutes.
