SMC MY1B50-900 RODLESS CYLINDER
Quick Overview
Manufactured By: SMC
Manufacturer Part Number: MY1B50-900
IMS Product Code: 1256243
Packaging: Sold Individually
Description:
SMC MY1B50-900 Rodless Cylinder
Mechanically jointed rodless cylinder with 50 mm bore diameter and 900 mm stroke. Double-acting with air cushion. Standard piping with 1/8 BSPT female port. Basic guide type.
Specifications
- Series: MY1
- Bore Diameter: 50 mm
- Stroke: 900 mm
- Cushion Type: Air Cushion
- Piston Action: Double-Acting
- Port Thread Standard: BSPT
- Port Size: 1/8 BSPT
- Port Gender: Female
- Operating Pressure Range: 14 to 116 psi
- Operating Temperature Range: 41 to 140 degrees F
- Overall Length: 1300 mm
- Overall Width: 92 mm
- Overall Height: 94 mm
- Mounting Type: Basic
- Guide Type: Basic Guide - Standard
- Weight: 30.86471 lb
