SMC VBA10A-02GN BOOSTER REGULATOR
Quick Overview
Manufactured By: SMC
Manufacturer Part Number: VBA10A-02GN
IMS Product Code: 1910931
Packaging: Sold Individually
Description:
SMC VBA10A-02GN Booster Regulator
Booster regulator that increases main line pressure up to two times, with handle-operated pressure adjustment and relief mechanism.
Specifications
- fluid: Compressed air
- pressure increase ratio: Twice
- max. flow rate: 230 L/min (ANR)
- set pressure range: 0.2 to 2.0 MPa
- supply pressure range: 0.1 to 1.0 MPa
- proof pressure: 3 MPa
- port size: 1/4
- pressure gauge port size: 1/8
- ambient and fluid temperature: 2 to 50 degrees C
- installation: Horizontal
- lubrication: Grease (Non-lube)
- weight: 0.84 kg
- height: 113 mm
- length: 70 mm
- width: 150 mm
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 1 hours and 24 minutes.
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 1 In Stock
Ships today if ordered in the next 2 hours and 24 minutes.
Used (Special):
MISSING 2 GAUGES
Availability: 1 In Stock
Ships today if ordered in the next 1 hours and 24 minutes.
