SQUARE D 9001KA1 CONTACT BLOCK
Quick Overview
Manufactured By: SQUARE D
Manufacturer Part Number: 9001 KA1
IMS Product Code: 1749011
Variation: Unspecified
Unspecified
Series: G
Series: H
Series: J
Series: K
Packaging: Sold Individually
Description:
Square D 9001KA1 Contact Block
30mm contact block with 1NO-1NC configuration, screw clamp terminals, rated for 10A, 600V AC/DC maximum.
Specifications
- Series: Harmony 9001K
- Connection Type: Screw Clamp Terminals
- Rated Current: 3A (IEC), 10A (UL/CSA)
- Rated Voltage: 250V (IEC), 600V AC/DC (UL/CSA)
- Contact Configuration: 1NO-1NC
- Contact Material: Silver Alloy
- Material: Nylon
- Size: 30mm
- Type: Finger Safe
- Standard: IEC 60947-5-1, UL 508, CSA C22.2 No 14
- IP Rating: IP20
