SQUARE D DU325 400A SAFETY SWITCH
Quick Overview
Manufactured By: SQUARE D
Manufacturer Part Number: DU325
IMS Product Code: 2145929
Packaging: Sold Individually
Description:
Square D DU325 400A Safety Switch
General duty safety switch for residential and commercial applications. 400A, 240V AC, 3-pole, non-fusible disconnect with NEMA 1 enclosure.
Specifications
- Line Rated Current: 400 A
- Number of Poles: 3
- Rated Operational Voltage: 240 V AC
- Nema Degree Of Protection: NEMA 1
- Device Mounting: surface
- Disconnector Device Type: non-fusible disconnect switch
- Electrical Connection: lugs
- Product Or Component Type: Single Throw Safety Switch
- Wiring Configuration: 3-wire
- Tightening Torque: 340-340 lbf.in (AWG 1/0...750 kcmil) || 340-340 lbf.in (2 x AWG 1/0...2 x 300 kcmil)
- Net Weight: 52 kg
- Type: Single Throw, General Duty Type
- Size: 24.88 Inch Width X 8.88 Inch Depth X 45.12 Inch Height
- Wire: 3 Wire(S)
- Approval: UL Approval
- Enclosure: NEMA 1 Enclosure
- Current Rating: 400 Amp
- Power Rating: 125 HP at 240 Volt AC 3-Phase
- Pole: 3 Pole(S)
- Neutral Type: No Neutral Type
- Operation Method: On/Off
- Current Type: AC/DC
- Type: Disconnector
- Maximum Amperage: 400 A
- Voltage: 240VAC
- Series: DU
- Amperage: 400
- Poles: 3
- Phase: 3
- Mounting Type: Surface
- Approval: UL, NEMA
- Interrupting Rating: 100kAIC at 240V
- Frame Type: DU
- Connection Type: Lugs
- Nema Rating: 1
- Wire Gauge: AWG 1/0 to 600KCmil Aluminum/Copper, 2 x AWG 1/0 to 2 x 300KCmil Aluminum/Copper
- Duty Rating: General Duty
- Fusibility: Non-Fusible
- Configuration: Single
- Number Of Wires: 3
- Contact Configuration: 3PST
