STEARNS 105602100BQF SPRING ACTUATED MAGNETIC BRAKE
Quick Overview
Manufactured By: STEARNS
Manufacturer Part Number: 105602100BQF
IMS Product Code: 2127798
Packaging: Sold Individually
Description:
Stearns 105602100BQF Spring Actuated Magnetic Brake
Spring actuated magnetic brake with 6 ft-lbs static torque, C-face mounting, 5/8" bore diameter, and IP23 enclosure rating.
Specifications
- Brake Type: Spring Actuated
- Nominal Static Torque: 6 ft-lbs
- Voltage Rating: 208-230 V ac, 460 V ac
- Bore Diameter: 5/8 in
- Mounting Type: C-Face
- Housing Material: Aluminum
- Number Of Friction Discs: 1
- Standards Met: CSA, UL
- Product Series: 56000
- Type: Disc Brakes
- NEMA: 2
- Phase: 3
- Torque: 6 Foot Pound
- Hub Bore: 5/8"
- Mount: Horizontal
- Coil Insulation: Class B
- Maximum Speed: 5000 RPM
- Enclosure: IP23
- Housing: Stamped Steel
- Certification: CSA File LR-6254
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
