STEGO 01116.9-00 DIN RAIL THERMOSTAT
Quick Overview
Manufactured By: STEGO
Manufacturer Part Number: 01116.9-00
IMS Product Code: 1881493
Packaging: Sold Individually
Description:
Stego 01116.9-00 DIN Rail Thermostat
DIN rail mount thermostat with thumbwheel temperature setting between 32-140 degrees F. Normally open (NO) contact configuration. Maximum voltage 250 VAC. Plastic housing, IP20 protection.
Specifications
- Scale / Range: 32 to 140 degrees F
- Voltage: 250 VAC max.
- Contact Type: NO / close on rise
- Sensor Element: Thermostatic bi-metal
- Switching Difference (Hysteresis): 7 degrees F ± 5.4 degrees F
- Switching Capacity (Max. Load): 15 A resistive/2 A inductive at 120 VAC, 10 A resistive/2 A inductive at 250 VAC, DC 30W (24 - 72 VDC)
- Minimum Load: 20 mA (all voltages)
- Connection: 2-pole terminal for AWG 14 max. (2.5mm2), torque 1Nm max.
- Mounting: Clip for 35 mm DIN rail (EN 60 715)
- Dimensions (H x W x D): 2.76 x 1.3 x 1.65 inches (70 x 33 x 42 mm)
- Housing: Plastic, UL 94V-0, light gray
- Weight (Approx.): 1.8 oz (50 g)
- Operating/Storage Temperature: -49 to 158 degrees F (-45 to 70 degrees C)
- Protection Type: IP20
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
