SUMITOMO 19RB857, SNMG322 ENG GRADE AC830P CARBIDE TURNING INSERT
Quick Overview
Brand: SUMITOMO
Part Number: 19RB857
IMS Product Code: 1791272
Packaging: Sold Individually
Description:
Sumitomo 19RB857, SNMG322 ENG Grade AC830P Carbide Turning Insert Al2O3 Finish, 90° Square, 3/8" Inscr Circle, 1/8" Thick, 1/32" Corner Radius
Specifications:
| Insert Style | SNMG |
| Insert Size | 322 |
| Material | Carbide |
| Inscribed Circle (Decimal Inch) | 0.3750 |
| Inscribed Circle (Inch) | 3/8 |
| Thickness (Inch) | 1/8 |
| Thickness (Decimal Inch) | 0.1250 |
| Corner Radius (Inch) | 1/32 |
| Corner Radius (Decimal Inch) | 0.0313 |
| Manufacturer's Grade | AC830P |
| Coating | Al2O3 |
| Chip breaker | ENG |
| Length (Inch) | 3/8 |
| Hole Diameter (Decimal Inch) | 0.1500 |
| Rake | Negative |
| Rake Angle | 4 |
| Relief Angle | 0 |
| Included Angle | 90 |
| Insert Holding Method | Pin & Clamp |
| Shape | Square |
