SUNX FD-G4 FIBER AMPLIFIER
Quick Overview
Manufactured By: SUNX
Manufacturer Part Number: FD-G4
IMS Product Code: 1802319
Packaging: Sold Individually
Description:
SUNX FD-G4 Fiber Amplifier
SUNX FD-G4 Fiber Amplifier, Digital, NPN, 4-Channel
Specifications
- Type: Fiber Amplifier
- Output Type: NPN
- Number of Channels: 4
- Connection Method: Pre-wired
- Operating Voltage: 12-24 VDC
- Current Consumption: 40 mA or less (at 24 VDC)
- Control Output: NPN open collector
- Response Time: 250 µs or less
- Protection Circuit: Reverse power supply connection protection, Output short-circuit protection
- Ambient Temperature: -10 to +55 degrees C (no freezing)
- Ambient Humidity: 35 to 85% RH (no condensation)
- Weight: approx. 80 g
- Dimensions: 65.5 x 30.8 x 13.2 mm
- Sensing Head: M4 threaded
- Fiber Style: Coaxial
- Cable Length: 2m
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 2 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
