SYSTEM SENSOR RTS151 REMOTE TEST STATION
Quick Overview
Manufactured By: SYSTEM SENSOR
Manufacturer Part Number: RTS151
IMS Product Code: 2149295
Packaging: Sold Individually
Description:
System Sensor RTS151 Remote Test Station
Remote test station for System Sensor smoke and fire detectors.
Specifications
- Operating Voltage: 12-33 VDC
- Operating Temperature: -4°F to 100°F (-20°C to 38°C)
- Relative Humidity: 0-93% non-condensing
- Detector Type: Rate-of-Rise and Fixed Temperature
- Mounting: Standard electrical box
- Power Requirements Alarm LED: 2.8 to 32 VDC, 12 mA max
- Total Current: 105 mA max
- Test Switch: 10 VA @ 32 VDC
- Reset Switch: 10 VA @ 32 VDC
- Alarm Response Time: 40 seconds max
- Wire Gauge: 14 to 18 AWG
- Dimensions: 4.8" H x 2.90" W x 1.4" D
- Temperature Rating: -10 to 60 deg C
- Humidity Rating: 95% RH Non-Condensing
- Mounting Type: Single Gang Box
- Alarm LED: 2.8 - 32 VDC, 10 mA maximum, Coil current: 95 mA maximum
- Supply Voltage: 24 VDC
- Alarm Auditory Levels: 85 db @ 10' (3.0m)
- Approvals: UL File #S4011 & #S2522, CSFM
- Country of Origin: Mexico
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
