TB WOODS F 3-3/8 DUCTILE IRON QD BUSHING
Quick Overview
Manufactured By: TB WOODS
Manufacturer Part Number: F 3-3/8
IMS Product Code: 1791925
Packaging: Sold Individually
Description:
TB Woods F 3-3/8 Ductile Iron QD Bushing
Ductile iron QD bushing with 3-3/8 inch bore, keyway, and 3 bolt holes.
Specifications
- Bushing Size: F
- Bore Diameter: 3.375 in
- Flange Outside Diameter: 6.625 in
- Flange Thickness: 0.8125 in
- Length Through Bore: 3.625 in
- Material: Ductile Iron
- Torque Capacity: 40000 in-lb
- Bolt Circle Diameter: 5-5/8 in
- Number Of Bolt Holes: 3
- Screw Thread Size: 9/16-12 in
- Screw Length: 3-5/8 in
- Keyway Size: 7/8 x 3/16 in
- Weight: 10.60 lbs
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 8 hours and 50 minutes.
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 8 hours and 50 minutes.
